توضیحات

-Accuracy
.Linearity better than 0.2% of set span
.Adjustable measuring range with
TD 10:1
.Long-term stability better than 0.1%
-Sensors
.Dry capacitive ceramic sensor up to 40 bar (600 psi) – corrosion and abrasion resistant with high overload protection and vacuum-tightness
.Piezoresistive metal sensor for measuring ranges up to 400 bar (6000 psi)
-Electronics
.Analogue: low-cost and accurate with short response time especially for rapid processes
.Smart: intelligent with versatile operating procedures via HART protocol
.PROFIBUS-PA: tried and tested for digital communications
-Housings:
With its stainless steel housing without dead volume, the Cerabar M fulfils all the special hygienic requirements of the food and pharmaceutical industries
The polyester-epoxy coated aluminium housing has been field-proven in the process industry
-Process connections:
All customary thread versions, hygienic connections and flanges are available
